Equipment

Various Nanosecond Pulse-Lasers

• Approx. 8 ns pulse duration
• 1064 nm, 532 nm, 355 nm, 266 nm
• Pulse energies
  @ 1024 nm up to 1100 mJ
  @ 532 nm up to 550 mJ
  @ 355 nm up to 350 mJ
  @ 266 nm up to 100 mJ
• Repetition rates 10 Hz up to 100 Hz
• Optical Parametric Oscillators (OPOs) for generation of tunable laser radiation

CW-Lasers

• 532 nm, 451 nm, 410 nm
• up to 12 W

CCD-Cameras

• Resolutions up to 1600 x 1200 pixels
• Repetition rates up to 100 Hz

Intensified CCD-Cameras

• Resolutions up to 1280 x 1024 pixels
• Exposure times from 3 ns, repetition rates up to 15 Hz
• spectral sensitivity from 200 nm up to 870 nm

Photomultiplier

• Rise-time 0,6 ns
• spectral response from 230 nm up to 920 nm

Automated Scheimpflug-Adapter

• Automated Scheimpflug-adapter for viewing angles from 15° to 165°

Ellipsoidal Mirrors

• Focal lengths from 360 mm to 600 mm
• Diameter from 150 mm to 250 mm

Imaging Fiberoptics

• Fiber bundle 8 or 9 individual arms for signal input
• output side combined
• total number of fibers approx. 1.04 million
• length per arm 2 m

Spark Discharge Generator

• Variable flow guidance
• Optical access
• Modular design

Scanning Mobility Particle Sizer

• Particle size from 8 nm to 1200 nm
• Particle concentrations up to 50000 1/cm³

Thermophoretical Probing Systems for TEM-Analysis

• Sampling durations from 10 ms to 1 s
• electromagnetic, mechanical, pneumatic

Burners

• Spray-Flame-Synthesis (SFS) burner
• Tethis-burner
• Diffusion burners for the production of soot or other nanoparticles
• Laminar premixed flat flame burner of Typ McKenna
• Gülder-burner

High Pressure Cells

• Optical access, pressures up to 900 bar
• Pneumatic Pistons for pressure jumps of several 100 bars within a few ms

Oscillating U-tube for Density-Measurements

• Densities up to 3 g/cm³, temperatures from -10 °C to 200 °C, pressure up to 700 bar
• Accuracy of density of 0.0001 g/cm³, accuracy of temperature of 0.05 °C

Other Devices

• Spectrometers of different wavelength ranges (200 nm – 1100 nm) and resolutions
• Power- and energy-meters for Lasers
• Beam-profiling cameras
• Oscilloscopes
• Pulse-delay-generators
• CEM-system
